XSP-20恒温平台显微镜
产品介绍XSP-20恒温平台显微镜(XSP-20 Thermostatic Platform Microscope)
放大倍数：640-1000倍
Magnification: 640-1000 times
目镜：WF16倍、WF25倍
Eyepiece: WF16 X, WF25X
物镜：185消色差物镜4倍、10倍、40倍
Objective:185 achromatic objective lens, 4X, 10X, 40X
观察镜筒：单目, 45°倾斜, 360°旋转
Observation lens barrel: Monocular ,45° tilt ,360° rotation
转换器：三孔钢珠内倾
Converter: Tri-hole steel ball inclination
载物台：单层方形平台，压片夹，120X110mm
Loading platform: Single layer square platform,Tablet clip ,120X110mm
工作距离：110X110mm
Working distance: 110X110mm
调焦机构：粗微调同轴，粗调18mm，微调0.002mm
Focusing mechanism: Coarse adjustment 18mm，Fine-tune the 0.002 mm
照明系统：LED冷光源，亮度可调
Lighting system: LED cold light source with adjustable brightness
电源：外置电源适配器，DC 12V(±10%)
Power supply: external power adapter, DC 12V (±10%)
